Vertisa Medical Waste Sterilization Devices PRE-150

How does it function?

PRE-150 Medical Waste Sterilization Device

  • Capacity: 33-70 kilograms per hour
  • Field of Utilization: Primarily for clinics and small hospitals
  • Optional Microwave-Induced Sterilization Process
  • Pressure container constructed from high-quality stainless steel
  • Design and production certified by TUV Austria
  • Manufactured in compliance with EU Directives PED (2014/68/EU), 2006/42/EC, 2014/30/EU & EU Norms EN285
  • Advanced automation control system with advanced reporting and monitoring software
  • Online access via the internet for supervision and troubleshooting
  • Optional automatic elevator system for easy loading
  • Zero water consumption
  • Low fuel and electrical consumption due to integrated steam boilers equipped with state-of-the-art steam regeneration system
  • Includes Vacuum Pump
  • Optional Odor Control System
Technical FeaturesValue
Size (L x W x H) (mm)2400 x 1450 x 1900
Weight (Kg)2930
Air Pressure (Bar max)8
Electrical connection required (Kw)35-45*
Working CharacteristicsValue
Sterilizing Capacity (Kg/ Cycle30-35
Sterilizing Capacity (Kg/ Hour)60 kg/h (even more depending on the bulk density of the waste)
Process Volume Capacity (Lt.)290
Average Waste Density (Kg/m3)100-150
Average Cycle Time (Min.)30
Maximum Steam Flow (Kg/Hour)170
Sterilization Efficiency (SAL)8Log10
Consumption / CycleValue
Steam (Kg)8
Electricity (Kw)1.7**
Water (Lt)None***
Special ConsumablesNone
